This Compact INS400 is a 4 poles non-automatic switch-disconnector with black rotary handle.
It is suitable for isolation with positive contact indication, as defined by IEC 60947-1 and IEC60947-3 standards.
The operational current is 400A at 415VAC in categories AC22A and AC23A.
The rated voltage is 690VAC 50/60Hz or 250VDC.
The black rotary handle is designed to offer easy operation and high performance in interruption of currents.
Compact INS400 is a class II insulation level front-face device as per IEC 60664 standard.
| Range | ComPact INS |
|---|---|
| Product/Component Type | Switch Disconnector |
| Poles | 4P |
| Rated Operational Voltage | 250 V DC 690 V AC 50/60 Hz |
