Schneider MCCB EasyPact CVS 100N - TM50D - 50 A - 3 poels 3d - circuit breaker - LV510474
Ready Stock
LV510474
Harga Spesial Rp1.371.960 Harga Reguler Rp2.743.920
IDR, Ind
Hoki Care
(021) 6121212
Live Chat
Operational Hours Senin - Jumat 08.30 - 17.00 & Sabtu 08.30 - 14.00
Deskripsi Produk
Deskripsi Produk
This device is a rated current 50A circuit breaker from EasyPact CVS250N.
The rated breaking capacity(Ics) is 50kA at 415VAC,and complete range with Ics=100%Icu.
The version of breaker is 3poles frame with detection on 3poles, also accompanied TM-D trip unit for thermal-magnetic protection.
It is conformed to standard IEC60947-2 for circuit breakers part.
This device is certified for operation in pollution degree III environment as defined IEC60947-1& IEC60664-1, and respected for RoHs requirement as european environment directive EC/2002/95.
It can be mounted by blackplate or Din rail,also through the door of class II switchboard without downgrading switchboard insulation.
The front of toggle offers IP40 protection, but when it is equiped extended rotary handle inside the switchboard, additional IP54 protection degree for extended rotary handle.
This series have slots for electrical auxiliaries(MN/MX/OF/SD),depending on the type of trip unit if rotary handle installed.
The fixed dimension is 140mm width.255mm height,110mm depth,
Spesifikasi
| Range | EasyPact CVS |
|---|---|
| Product/Component Type | MCCB |
| Poles description | 3P |
| [In] rated current | 50 A at 40 °C |
| Trip unit name | TM-D |
| Device short name | 100N |
| Instantaneous Pick Up Adjustment Range | 500 A |
